ALENOR BF-FR REINFORCED BUTYL TAPE

ALENOR BF Facade Butyl Tape – is aluminium foil reinforced tape based on a butyl rubber sealant composition with permanent adhesion, which is protected by a silicone paper. Have perfect adhesion to different surfaces, such as: glass, aluminum, steel, plastics, and other construction surfaces.

Product composition: аluminum foil, non-woven fabric, bottle-rubber composition, anti-adhesive material.

Scope of application:

  • • used in the installation of faсade transom systems. It is installed under the pressure bar
  • • provides sealing of joints between double-glazed windows, sandwich panels and other fillers for sustainable transom systems

Advantages:

  • • has high adhesion, due to the proprietary formulation of the butyl rubber composition
  • • аvailable in different widths, from 40 to 150 mm, suitable for use in rack-transom systems of all manufacturers
  • • due to the non-woven fabric, which performs a reinforcing function, it is durable and resistant to linear stretching
  • • easy to install, does not tear, does not screw on a self-tapping screw
  • • self-seals in case of punctures and cuts
  • • has proven itself in low and high temperatures (-40…+100oС)
  • • does not contain substances harmful to life

Name Value
Tape cover color metallic
Tape butyl rubber compound color grey
Vapor permeability, mg/ (m²×h×Pa) 0.0002
Watertightness yes
Adhesion to concrete, MPa 0,3
Adhesion to steel, MPa 0,4
Temperature of usage, °С – 40 … + 100
Installation temperatures, °С + 5 … + 40
Shelf life in original packing, month 36
Working life (no less then), years 10
Thickness, mm

Tolerance ± 0,2 mm

Width, mm

Tolerance ± 2 mm

Length, m

Tolerance ± 1.5%

0,8 Standard: 45
On request: 40; 50; 63; 75; 100; 120; 150
10
